Ethernet

Standards:

IEEE 802.3 10Base-T Ethernet

IEEE 802.3u 100Base-TX Fast Ethernet

IEEE 802.3ab 1000Base-T Gigabit Ethernet

IEEE 802.3bz 2.5G/5G/10GBASE-T

Processing Type:

Pass-Through

10Gbps Full-Duplex

Data Rate:

10M/100M/1G/2.5G/5G/10Gbps

Network Cable:

Twisted-pair cable up to 100 meters (328ft)

10BASE-T: 4-pair UTP Cat. 3, 4, 5, 5e, 6, 6A

100BASE-TX: 4-pair UTP Cat. 5, 5e, 6, 6A

1G/2.5G: 4-pair UTP Cat 5e/Cat 6/Cat 6A/ Cat 7

5G: 4-pair UTP Cat 6/Cat 6A/Cat 7

10G:4-pair UTP Cat 6A/Cat 7

Connector:

LAN: 1 x RJ-45, “Data” Input Port

POE: 1 x RJ-45, “Data + Power” Output Port

DC Connector: 1 x 12V DC Output Jack (5.5mm / 2.1mm)

AC Connector: 1 x AC Input power socket, IEC-60320 C13

Environmental

Operating Temperature:

-20°C to 75°C (-4°F to 167°F)

Storage Temperature:

-40°C to 70°C (-40°F to 167°F)

Relative Humidity:

5% to 95% non-condensing

MTBF:

>200,000hrs

Electrical

Input Voltage Range:

100-240V AC @50/60Hz

Auxiliary DC Output:

Voltage: 12V DC

Current: 1.5A Max

Power Switch:

Integrated Rear Rocker Switch (ON / OFF)

Power Consumption:

120 watts max.

Protection:

Short-Circuit Protection, Over-Current Protection, Over-Voltage Protection

PoE (Power over Ethernet)

Standard:

IEEE 802.3af Power over Ethernet

IEEE 802.3at Power over Ethernet Plus

IEEE 802.3bt 4-pair Power over Ethernet (Type 4)

Port:

RJ45

Power Pin Assignment

4-Pair (Pair 1/2/4/5 +, Pair 3/6/7/8 -)

PoE Power Output

Voltage: 56V DC

Max Power: 95W

LED Indicators

DC:

12V DC Output Status

PoE:

PoE Status

Mechanical

Dimensions (W×D×H):

191 x 73 x 45mm

Weight:

650g

Casing:

Aluminum Shell with Wall-Mount Brackets/Flanges

Mounting Options:

Desktop/Wall-mount

Regulatory Approvals

ISO9001

FCC part 15, Class A

EN55022:2006+A1: 2007 Class A

Surge Protection:

RJ45: 1KV

Power: 500V

ESD: 4KV/8KV
